gn是什么?

gn 存在的意义是为了生成 ninja,如果熟悉前端开发,二者关系很像 SassCSS的关系。 为什么会有gn,说是有个叫even的谷歌负责构建系统的工程师在使用传统的makefile构建chrome时觉得太麻烦,不高效,所以设计了一套更简单,更高效新的构建工具gn+ninja,然后就被广泛的使用了。

gn语法和配置

gn 有大量的内置变量和库函数,熟悉这些库函数基本就知道gn能干什么,gn的官方文档很齐全,前往 gn参考手册翻看查找 。 gn 的语法简单,了解以下几点基本就能看懂gn代码。重点了解下函数的调用方式,和其他高级语言不太一样。

字符串

a = "mypath"
b = "$a/foo.cc"  # b -> "mypath/foo.cc"
c = "foo${a}bar.cc"  # c -> "foomypathbar.cc"
1
2
3

列表

a = [ "first" ]
a += [ "second" ]  # [ "first", "second" ]
a += [ "third", "fourth" ]  # [ "first", "second", "third", "fourth" ]
b = a + [ "fifth" ]  # [ "first", "second", "third", "fourth", "fifth" ]
1
2
3
4

条件语句

if (is_linux || (is_win && target_cpu == "x86")) {
    sources -= [ "something.cc" ]
  }else {
    ...
  }
1
2
3
4
5

循环

foreach(i, mylist) {
  print(i)  # Note: i is a copy of each element, not a reference to it.
}
1
2
3

函数调用

print("hello, world")
assert(is_win, "This should only be executed on Windows") # 如果is_win为真,就打印后面的内容
static_library("mylibrary") {
  sources = [ "a.cc" ]
}
1
2
3
4
5

解读:

  • printassertstatic_library都是库函数,或者叫内置函数。
  • static_library的调用有点奇怪,它是个函数,函数内部会使用sources这个内置变量,sources = [ "a.cc" ]相当于先传参给这个函数的内置变量,并调用这个函数。学习ng得习惯这种语法方式,被大量的使用。

模板 | Templates

gn提供了很多内置函数,使用偏傻瓜式,若构建不复杂的系统,熟悉这些内置函数,选择填空就可以交作业了,如果想高阶点,想自己定义函数怎么办? 答案是模板,模板就是自定义函数。

#定义模板, 文件路径: //tools/idl_compiler.gni, 后缀.gni 代表这是一个 gn import file
template("idl") { #自定义一个名称为 "idl"的函数
  source_set(target_name) { #调用内置函数 source_set
    sources = invoker.sources #invoker为内置变量,含义为调用者内容 即:[ "a", "b" ]的内容
  }
}
1
2
3
4
5
6
#如何使用模板, 用import,类似 C语言的 #include
import("//tools/idl_compiler.gni")
idl("my_interfaces") { #等同于调用 idl
  sources = [ "a", "b" ] #给idl传参, 参数的接收方是 invoker.sources
}
1
2
3
4
5

明白了模板的使用,阅读鸿蒙gn代码就不会有太大的障碍。

目标项 | Targets

目标是构建图中的一个节点。它通常表示将生成某种可执行文件或库文件。整个构建是由一个个的目标组成。 目标包含:

action: 运行脚本以生成文件
executable: 生成可执行文件
group: 生成依赖关系组
shared_library: 生成.dll或.so动态链接库
static_library: 生成.lib或.a 静态链接库
...
1
2
3
4
5
6

配置项 | Configs

记录完成目标项所需的配置信息,例如:

config("myconfig") {#创建一个标签为`myconfig`的配置项
    include_dirs = [ "include/common" ]
    defines = [ "ENABLE_DOOM_MELON" ]
  }

executable("mything") {#生成可执行文件
  configs = [ ":myconfig" ]#使用标签为`myconfig`的配置项来生成目标文件
}
1
2
3
4
5
6
7
8

gn在鸿蒙中的使用

有了以上基础铺垫,正式开始gnopenharomny中的使用。

从哪开始

在构建工具篇中已经说清楚了 hbpython部分有个工作任务是生成gn命令所需参数. gn生成ninja的命令是 gn gen ...

  /home/tools/gn gen /home/openharmony/code-v1.1.1-LTS/out/hispark_aries/ipcamera_hispark_aries \
  --root=/home/openharmony/code-v1.1.1-LTS \
  --dotfile=/home/openharmony/code-v1.1.1-LTS/build/lite/.gn \
  --script-executable=python3 \
  '--args=ohos_build_type="debug" \
          ohos_build_compiler_specified="clang" \
          ohos_build_compiler_dir="/home/tools/llvm" \
          product_path="/home/openharmony/code-v1.1.1-LTS/vendor/hisilicon/hispark_aries" \
          device_path="/home/openharmony/code-v1.1.1-LTS/device/hisilicon/hispark_aries/sdk_liteos" \
          ohos_kernel_type="liteos_a" \
          enable_ohos_appexecfwk_feature_ability = false \
          ohos_full_compile=true'
1
2
3
4
5
6
7
8
9
10
11
12

解读

  • rootdotfilescript-executable是gn内置的固定参数,一切从dotfile指向的文件开始。即build/lite/.gn 相当于main()函数的作用,

  • 打开 build/lite/.gn看下内容,只有两句,先配置好内部参数再工作。

    # The location of the build configuration file. #1.完成gn的配置工作
    buildconfig = "//build/lite/config/BUILDCONFIG.gn"

    # The source root location. #2.完成gn的编译工作
    root = "//build/lite"

    1
    2
    3
    4
    5
  • args为用户自定义的参数,它们将会在解析BUILD.gnBUILDCONFIG.gn过程中被使用。

BUILDCONFIG.gn | 构建配置项

BUILDCONFIG.gnBUILD.gn做准备,填充好编译所需的配置信息。即生成配置项 详细请查看 build/lite/config/BUILDCONFIG.gn 文件全部内容,本篇只贴出部分。

import("//build/lite/ohos_var.gni")
import("${device_path}/config.gni")
....
arch = "arm"
if (ohos_kernel_type == "liteos_a") {
  target_triple = "$arch-liteos"
} else if (ohos_kernel_type == "linux") {
  target_triple = "$arch-linux-ohosmusl"
}
...
template("executable") { #生成可执行文件
  executable(target_name) {
    forward_variables_from(invoker, Variables_Executable)
    if (!defined(invoker.deps)) {
      deps = [ "//build/lite:prebuilts" ]
    } else {
      deps += [ "//build/lite:prebuilts" ]
    }
    if (defined(invoker.configs)) {
      configs = []
      configs += invoker.configs
    }
  }
}
set_defaults("executable") {#设置目标类型的默认值
  configs = default_executable_configs
  configs += [ "//build/lite/config:board_exe_ld_flags" ]
}
...
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

解读

  • ${device_path}为命令行参数,本篇为home/openharmony/code-v1.1.1-LTS/device/hisilicon/hispark_aries/sdk_liteos
  • 查看构建-配置内容,BUILDCONFIG主要任务就是对其中的内置变量赋值。例如:
    • 指定编译器 clang,
    • 如何生成可执行文件的方法等

BUILD.gn | 启动构建

查看 build/lite/BUILD.gn 文件,文件注解较多。

#目的是要得到项目各个模块的编译入口
group("ohos") {
  deps = []
  if (ohos_build_target == "") {
    # Step 1: Read product configuration profile。
    # 第一步:读取配置文件product_path的值来源于根目录的ohos_config.json,如下,内容由 hb set 命令生成
    # {
    #  "root_path": "/home/openharmony",
    #  "board": "hispark_aries",
    #  "kernel": "liteos_a",
    #  "product": "ipcamera_hispark_aries",
    #  "product_path": "/home/openharmony/vendor/hisilicon/hispark_aries",
    #  "device_path": "/home/openharmony/device/hisilicon/hispark_aries/sdk_liteos",
    #  "patch_cache": null
    #}
    product_cfg = read_file("${product_path}/config.json", "json")

    # Step 2: Loop subsystems configured by product.
    # 第二步:循环处理各自子系统,config.json中子系统部分格式如下hb
    #"subsystems": [
    #  {
    #    "subsystem": "aafwk",
    #    "components": [
    #      { "component": "ability", "features":[ "enable_ohos_appexecfwk_feature_ability = false" ] }
    #    ]
    #  },
    #  ...
    #  {
    #    "subsystem": "distributed_schedule",
    #    "components": [
    #  	{ "component": "system_ability_manager", "features":[] },
    #  	{ "component": "foundation", "features":[] },
    #  	{ "component": "distributed_schedule", "features":[] }
    #    ]
    #  },
    #  {
    #      "subsystem": "kernel",
    #      "components": [
    #        { "component": "liteos_a", "features":[] }
    #      ]
    #   },
    #]
    foreach(product_configed_subsystem, product_cfg.subsystems) {#对子系统数组遍历操作
      subsystem_name = product_configed_subsystem.subsystem	#读取一个子系统 aafwk,hiviewdfx,security ==
      subsystem_info = {
      }

      # Step 3: Read OS subsystems profile.
	    # 第三步: 读取各个子系统的配置文件
      subsystem_info =
          read_file("//build/lite/components/${subsystem_name}.json", "json")

      # Step 4: Loop components configured by product.
      # 第四步: 循环读取子系统内各控件的配置信息
      # 此处以内核为例://build/lite/components/kernel.json"
      # "components": [
      #   {
      #     "component": "liteos_a",              # 组件名称
      #     "description": "liteos-a kernel",     # 组件一句话功能描述
      #     "optional": "false",                  # 组件是否为最小系统必选
      #     "dirs": [                             # 组件源码路径
      #       "kernel/liteos_a"
      #     ],
      #     "targets": [                          # 组件编译入口
      #       "//kernel/liteos_a:kernel"
      #     ],
      #     "rom": "1.98MB",                      # 组件ROM值
      #     "ram": "",                            # 组件RAM估值
      #     "output": [                           # 组件编译输出
      #       "liteos.bin"
      #     ],
      #     "adapted_board": [                    # 组件已适配的主板
      #       "hispark_aries",
      #       "hispark_taurus",
      #       "hi3518ev300",
      # 	  "hi3516dv300",
      #     ],
      #     "adapted_kernel": [ "liteos_a" ],     # 组件已适配的内核
      #     "features": [],                       # 组件可配置的特性
      #     "deps": {
      #       "components": [],                   # 组件依赖的其他组件
      #       "third_party": [                    # 组件依赖的三方开源软件
      #         "FreeBSD",
      #         "musl",
      #         "zlib",
      #         "FatFs",
      #         "Linux_Kernel",
      #         "lwip",
      #         "NuttX",
      #         "mtd-utils"
      #       ]
      #     }
      #   },
      # ]
      foreach(product_configed_component,
              product_configed_subsystem.components) { #遍历项目控件数组
        # Step 5: Check whether the component configured by product is exist.
		    # 第五步: 检查控件配置信息是否存在
        component_found = false #初始为不存在
        foreach(system_component, subsystem_info.components) {#项目控件和子系统中的控件遍历对比
          if (product_configed_component.component ==
              system_component.component) { #找到了liteos_a
            component_found = true
          }
        }
		    #如果没找到的信息,则打印项目控件查找失败日志
        assert(
            component_found,
            "Component \"${product_configed_component.component}\" not found" +
                ", please check your product configuration.")

        # Step 6: Loop OS components and check validity of product configuration.
		# 第六步: 检查子系统控件的有效性并遍历控件组,处理各个控件
        foreach(component, subsystem_info.components) {
          kernel_valid = false	#检查内核
          board_valid = false	#检查开发板

          # Step 6.1: Skip component which not configured by product.
          if (component.component == product_configed_component.component) {
            # Step 6.1.1: Loop OS components adapted kernel type.
            foreach(component_adapted_kernel, component.adapted_kernel) {
              if (component_adapted_kernel == product_cfg.kernel_type &&
                  kernel_valid == false) { #内核检测是否已适配
                kernel_valid = true
              }
            }
			# 如果内核未适配,则打印未适配日志
            assert(
                kernel_valid,
                "Invalid component configed, ${subsystem_name}:${product_configed_component.component} " + "not available for kernel: ${product_cfg.kernel_type}!")

            # Step 6.1.2: Add valid component for compiling.
			# 添加有效组件进行编译
            foreach(component_target, component.targets) {//遍历组件的编译入口
              deps += [ component_target ] #添加到编译列表中
            }
          }
        }
      }
    }

    # Step 7: Add device and product target by default.
    # 第七步: 添加设备和项目的编译单元
    # "product_path": "/home/openharmony/vendor/hisilicon/hispark_aries",
    # "device_path": "/home/openharmony/device/hisilicon/hispark_aries/sdk_liteos",
      deps += [
      "${device_path}/../", #添加 //device/hisilicon/hispark_aries 进入编译项
      "${product_path}"		#添加 //vendor/hisilicon/hispark_aries 进入编译项
    ]
  } else {#编译指定的组件,例如 hb build -T targetA&&targetB
    deps += string_split(ohos_build_target, "&&")
  }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153

解读

  • 有三个概念贯彻整个鸿蒙系统,子系统(subsystems),组件(components),功能(features)。理解它们的定位和特点是解读鸿蒙的关键所在。

  • 先找到product_path下的 配置文件 config.json,里面配置了项目所要使用的子系统和组件。

  • 再遍历项目所使用的组件是否能再 //build/lite/components/*。json组件集中能找到。

  • 将找到的组件targets加入到编译列表deps中.targets指向了要编译的组件目录。例如内核组件时指向了://kernel/liteos_a:kernel

    import("//build/lite/config/component/lite_component.gni") #组件模板函数
    import("//build/lite/config/subsystem/lite_subsystem.gni") #子系统模板函数
    lite_subsystem("kernel") {#编译内核子系统/组件入口
      subsystem_components = []

      if (enable_ohos_kernel_liteos_a_ext_build == false) {
        subsystem_components += [
          "//kernel/liteos_a/kernel",
          "//kernel/liteos_a/net",
          "//kernel/liteos_a/lib",
          "//kernel/liteos_a/compat",
          "//kernel/liteos_a/fs",
          "//kernel/liteos_a/arch:platform_cpu",
        ]
        if (LOSCFG_SHELL) {
          subsystem_components += [ "//kernel/liteos_a/shell" ]
        }
      } else {
        deps = [ ":make" ]
      }
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21

    lite_subsystem是个模板函数(自定义函数),再查看lite_subsystem.gni函数原型,它的目的只有一个填充 depsdeps是私有链接依赖关系,最终会形成一颗依赖树.gn会根据这些依赖关系生成最终的.ninja文件。

    # 定义一个子系统
    # lite_subsystem template模板定义了子系统中包含的所有模块
    # 参数
    #   subsystem_components (必须))
    #     [范围列表] 定义子系统的所有模块。
    template("lite_subsystem") {
        assert(defined(invoker.subsystem_components), "subsystem_components in required.")

        lite_subsystem_components = invoker.subsystem_components

        group(target_name) {
            deps = []
            if(defined(invoker.deps)) {
                deps += invoker.deps
            }
            # add subsystem packages
            foreach(pkg_label, lite_subsystem_components) {
                deps += [ pkg_label ]
            }
        }
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21

生成了哪些文件

执行后gn gen会生成如下文件和目录

turing@ubuntu:/home/openharmony/code-v1.1.1-LTS/out/hispark_aries/ipcamera_hispark_aries$ ls
args.gn  build.ninja  build.ninja.d  NOTICE_FILE  obj  test_info  toolchain.ninja
1
2

build.ninja.d中记录依赖的 BUILD.gn文件路径

build.ninja: ../../../base/global/resmgr_lite/frameworks/resmgr_lite/BUILD.gn \
             ../../../base/hiviewdfx/hilog_lite/frameworks/featured/BUILD.gn \
             ../../../base/hiviewdfx/hilog_lite/services/apphilogcat/BUILD.gn \
             ....
1
2
3
4

gn根据这些组件的BUILD.gnobj目录下对应生成了每个组件的.ninja文件。此处列出鸿蒙L1所有的 .ninja文件, 具体ninja是如何编译成最终的库和可执行文件的,将在后续篇中详细介绍其语法和应用。

turing@ubuntu:/home/openharmony/code-v1.1.1-LTS/out/hispark_aries/ipcamera_hispark_aries/obj$ tree
├── base
│   ├── global
│   │   └── resmgr_lite
│   │       └── frameworks
│   │           └── resmgr_lite
│   │               └── global_resmgr.ninja
│   ├── hiviewdfx
│   │   └── hilog_lite
│   │       ├── frameworks
│   │       │   └── featured
│   │       │       ├── hilog_shared.ninja
│   │       │       └── hilog_static.ninja
│   │       └── services
│   │           ├── apphilogcat
│   │           │   ├── apphilogcat.ninja
│   │           │   └── apphilogcat_static.ninja
│   │           └── hilogcat
│   │               ├── hilogcat.ninja
│   │               └── hilogcat_static.ninja
│   ├── security
│   │   ├── appverify
│   │   │   └── interfaces
│   │   │       └── innerkits
│   │   │           └── appverify_lite
│   │   │               ├── products
│   │   │               │   └── ipcamera
│   │   │               │       └── verify_base.ninja
│   │   │               ├── unittest
│   │   │               │   └── app_verify_test.ninja
│   │   │               └── verify.ninja
│   │   ├── deviceauth
│   │   │   └── frameworks
│   │   │       └── deviceauth_lite
│   │   │           └── source
│   │   │               └── hichainsdk.ninja
│   │   ├── huks
│   │   │   └── frameworks
│   │   │       └── huks_lite
│   │   │           └── source
│   │   │               └── huks.ninja
│   │   └── permission
│   │       └── services
│   │           └── permission_lite
│   │               ├── ipc_auth
│   │               │   └── ipc_auth_target.ninja
│   │               ├── pms
│   │               │   └── pms_target.ninja
│   │               ├── pms_base
│   │               │   └── pms_base.ninja
│   │               └── pms_client
│   │                   └── pms_client.ninja
│   └── startup
│       ├── appspawn_lite
│       │   └── services
│       │       ├── appspawn.ninja
│       │       └── test
│       │           └── unittest
│       │               └── common
│       │                   └── appspawn_test.ninja
│       ├── bootstrap_lite
│       │   └── services
│       │       └── source
│       │           └── bootstrap.ninja
│       ├── init_lite
│       │   └── services
│       │       ├── init.ninja
│       │       └── test
│       │           └── unittest
│       │               └── common
│       │                   └── init_test.ninja
│       └── syspara_lite
│           └── frameworks
│               ├── parameter
│               │   └── src
│               │       └── sysparam.ninja
│               ├── token
│               │   └── token_shared.ninja
│               └── unittest
│                   └── parameter
│                       └── ParameterTest.ninja
├── build
│   └── lite
│       └── config
│           └── component
│               ├── cJSON
│               │   ├── cjson_shared.ninja
│               │   └── cjson_static.ninja
│               ├── openssl
│               │   ├── openssl_shared.ninja
│               │   └── openssl_static.ninja
│               └── zlib
│                   ├── zlib_shared.ninja
│                   └── zlib_static.ninja
├── drivers
│   ├── adapter
│   │   └── uhdf
│   │       ├── manager
│   │       │   └── hdf_core.ninja
│   │       ├── platform
│   │       │   └── hdf_platform.ninja
│   │       ├── posix
│   │       │   └── hdf_posix_osal.ninja
│   │       └── test
│   │           └── unittest
│   │               ├── common
│   │               │   └── hdf_test_common.ninja
│   │               ├── config
│   │               │   └── hdf_adapter_uhdf_test_config.ninja
│   │               ├── manager
│   │               │   ├── hdf_adapter_uhdf_test_door.ninja
│   │               │   ├── hdf_adapter_uhdf_test_ioservice.ninja
│   │               │   ├── hdf_adapter_uhdf_test_manager.ninja
│   │               │   └── hdf_adapter_uhdf_test_sbuf.ninja
│   │               ├── osal
│   │               │   └── hdf_adapter_uhdf_test_osal.ninja
│   │               └── platform
│   │                   └── hdf_adapter_uhdf_test_platform.ninja
│   └── peripheral
│       ├── input
│       │   └── hal
│       │       └── hdi_input.ninja
│       └── wlan
│           ├── client
│           │   └── wifi_driver_client.ninja
│           ├── hal
│           │   └── wifi_hal.ninja
│           └── test
│               ├── performance
│               │   └── hdf_peripheral_wlan_test_performance.ninja
│               └── unittest
│                   └── hdf_peripheral_wlan_test.ninja
├── foundation
│   ├── aafwk
│   │   └── aafwk_lite
│   │       ├── frameworks
│   │       │   ├── ability_lite
│   │       │   │   └── ability.ninja
│   │       │   ├── abilitymgr_lite
│   │       │   │   └── abilitymanager.ninja
│   │       │   └── want_lite
│   │       │       └── want.ninja
│   │       └── services
│   │           └── abilitymgr_lite
│   │               ├── abilityms.ninja
│   │               ├── tools
│   │               │   └── aa.ninja
│   │               └── unittest
│   │                   └── test_lv0
│   │                       └── page_ability_test
│   │                           └── ability_test_pageAbilityTest_lv0.ninja
│   ├── ai
│   │   └── engine
│   │       ├── services
│   │       │   ├── client
│   │       │   │   ├── ai_client.ninja
│   │       │   │   ├── client_executor
│   │       │   │   │   └── client_executor.ninja
│   │       │   │   └── communication_adapter
│   │       │   │       └── ai_communication_adapter.ninja
│   │       │   ├── common
│   │       │   │   ├── platform
│   │       │   │   │   ├── dl_operation
│   │       │   │   │   │   └── dlOperation.ninja
│   │       │   │   │   ├── event
│   │       │   │   │   │   └── event.ninja
│   │       │   │   │   ├── lock
│   │       │   │   │   │   └── lock.ninja
│   │       │   │   │   ├── os_wrapper
│   │       │   │   │   │   └── ipc
│   │       │   │   │   │       └── aie_ipc.ninja
│   │       │   │   │   ├── semaphore
│   │       │   │   │   │   └── semaphore.ninja
│   │       │   │   │   ├── threadpool
│   │       │   │   │   │   └── threadpool.ninja
│   │       │   │   │   └── time
│   │       │   │   │       └── time.ninja
│   │       │   │   ├── protocol
│   │       │   │   │   └── data_channel
│   │       │   │   │       └── data_channel.ninja
│   │       │   │   └── utils
│   │       │   │       └── encdec
│   │       │   │           └── encdec.ninja
│   │       │   └── server
│   │       │       ├── ai_server.ninja
│   │       │       ├── communication_adapter
│   │       │       │   └── ai_communication_adapter.ninja
│   │       │       ├── plugin_manager
│   │       │       │   └── plugin_manager.ninja
│   │       │       └── server_executor
│   │       │           └── server_executor.ninja
│   │       └── test
│   │           ├── common
│   │           │   ├── ai_test_common.ninja
│   │           │   └── dl_operation
│   │           │       └── dl_operation_so
│   │           │           └── dlOperationSo.ninja
│   │           ├── function
│   │           │   ├── ai_test_function.ninja
│   │           │   └── death_callback
│   │           │       ├── testDeathCallbackLibrary.ninja
│   │           │       └── testDeathCallback.ninja
│   │           ├── performance
│   │           │   └── ai_test_performance_unittest.ninja
│   │           └── sample
│   │               ├── asyncDemoPluginCode.ninja
│   │               ├── sample_plugin_1.ninja
│   │               ├── sample_plugin_2.ninja
│   │               └── syncDemoPluginCode.ninja
│   ├── appexecfwk
│   │   └── appexecfwk_lite
│   │       ├── frameworks
│   │       │   └── bundle_lite
│   │       │       └── bundle.ninja
│   │       └── services
│   │           └── bundlemgr_lite
│   │               ├── bundle_daemon
│   │               │   └── bundle_daemon.ninja
│   │               ├── bundlems.ninja
│   │               └── tools
│   │                   └── bm.ninja
│   ├── communication
│   │   ├── ipc_lite
│   │   │   └── liteipc_adapter.ninja
│   │   └── softbus_lite
│   │       └── softbus_lite.ninja
│   ├── distributedschedule
│   │   ├── dmsfwk_lite
│   │   │   ├── dmslite.ninja
│   │   │   └── moduletest
│   │   │       └── dtbschedmgr_lite
│   │   │           └── distributed_schedule_test_dms.ninja
│   │   ├── safwk_lite
│   │   │   └── foundation.ninja
│   │   └── samgr_lite
│   │       ├── communication
│   │       │   └── broadcast
│   │       │       └── broadcast.ninja
│   │       ├── samgr
│   │       │   ├── adapter
│   │       │   │   └── samgr_adapter.ninja
│   │       │   ├── samgr.ninja
│   │       │   └── source
│   │       │       └── samgr_source.ninja
│   │       ├── samgr_client
│   │       │   └── client.ninja
│   │       ├── samgr_endpoint
│   │       │   ├── endpoint_source.ninja
│   │       │   └── store_source.ninja
│   │       └── samgr_server
│   │           └── server.ninja
│   ├── graphic
│   │   ├── surface
│   │   │   ├── surface.ninja
│   │   │   └── test
│   │   │       └── lite_surface_unittest.ninja
│   │   ├── ui
│   │   │   └── ui.ninja
│   │   ├── utils
│   │   │   ├── graphic_hals.ninja
│   │   │   ├── graphic_utils.ninja
│   │   │   └── test
│   │   │       ├── graphic_test_color.ninja
│   │   │       ├── graphic_test_container.ninja
│   │   │       ├── graphic_test_geometry2d.ninja
│   │   │       ├── graphic_test_math.ninja
│   │   │       └── graphic_test_style.ninja
│   │   └── wms
│   │       ├── wms_client.ninja
│   │       └── wms_server.ninja
│   └── multimedia
│       ├── audio_lite
│       │   └── frameworks
│       │       └── audio_capturer_lite.ninja
│       ├── camera_lite
│       │   └── frameworks
│       │       └── camera_lite.ninja
│       ├── media_lite
│       │   ├── frameworks
│       │   │   ├── player_lite
│       │   │   │   └── player_lite.ninja
│       │   │   └── recorder_lite
│       │   │       └── recorder_lite.ninja
│       │   ├── interfaces
│       │   │   └── kits
│       │   │       └── player_lite
│       │   │           └── js
│       │   │               └── builtin
│       │   │                   └── audio_lite_api.ninja
│       │   └── services
│       │       └── media_server.ninja
│       └── utils
│           └── lite
│               └── media_common.ninja
├── test
│   ├── developertest
│   │   ├── examples
│   │   │   └── lite
│   │   │       └── cxx_demo
│   │   │           └── test
│   │   │               └── unittest
│   │   │                   └── common
│   │   │                       └── CalcSubTest.ninja
│   │   └── third_party
│   │       └── lib
│   │           └── cpp
│   │               ├── gtest_main.ninja
│   │               └── gtest.ninja
│   └── xts
│       ├── acts
│       │   ├── aafwk_lite
│       │   │   └── ability_posix
│       │   │       └── module_ActsAbilityMgrTest.ninja
│       │   ├── ai_lite
│       │   │   └── ai_engine_posix
│       │   │       └── base
│       │   │           ├── module_ActsAiEngineTest.ninja
│       │   │           └── src
│       │   │               └── sample
│       │   │                   ├── asyncDemoPluginCode.ninja
│       │   │                   ├── sample_plugin_1_sync.ninja
│       │   │                   ├── sample_plugin_2_async.ninja
│       │   │                   └── syncDemoPluginCode.ninja
│       │   ├── appexecfwk_lite
│       │   │   └── bundle_mgr_posix
│       │   │       └── module_ActsBundleMgrTest.ninja
│       │   ├── communication_lite
│       │   │   ├── lwip_posix
│       │   │   │   └── module_ActsLwipTest.ninja
│       │   │   └── softbus_posix
│       │   │       └── module_ActsSoftBusTest.ninja
│       │   ├── distributed_schedule_lite
│       │   │   └── samgr_posix
│       │   │       └── module_ActsSamgrTest.ninja
│       │   ├── graphic_lite
│       │   │   ├── graphic_utils
│       │   │   │   ├── a
│       │   │   │   │   └── module_ActsUiInterfaceTest1.ninja
│       │   │   │   ├── color_posix
│       │   │   │   │   └── module_ActsColorTest.ninja
│       │   │   │   ├── geometry2d_posix
│       │   │   │   │   └── module_ActsGeometyr2dTest.ninja
│       │   │   │   ├── graphic_math_posix
│       │   │   │   │   └── module_ActsGraphicMathTest.ninja
│       │   │   │   ├── heap_base_posix
│       │   │   │   │   └── module_ActsHeapBaseTest.ninja
│       │   │   │   ├── list_posix
│       │   │   │   │   └── module_ActsListTest.ninja
│       │   │   │   ├── mem_api_posix
│       │   │   │   │   └── module_ActsGraphMemApiTest.ninja
│       │   │   │   ├── rect_posix
│       │   │   │   │   └── module_ActsRectTest.ninja
│       │   │   │   ├── transform_posix
│       │   │   │   │   └── module_ActsTransformTest.ninja
│       │   │   │   └── version_posix
│       │   │   │       └── module_ActsGraphVersionTest.ninja
│       │   │   ├── surface
│       │   │   │   └── surface_posix
│       │   │   │       └── module_ActsSurfaceTest.ninja
│       │   │   └── ui
│       │   │       ├── a
│       │   │       │   └── module_ActsUiInterfaceTest.ninja
│       │   │       ├── animator_posix
│       │   │       │   └── module_ActsAnimatorTest.ninja
│       │   │       ├── easing_equation_posix
│       │   │       │   └── module_ActsEasingEquationTest.ninja
│       │   │       ├── events_posix
│       │   │       │   └── module_ActsEventsTest.ninja
│       │   │       ├── flexlayout_posix
│       │   │       │   └── module_ActsFlexlaoutTest.ninja
│       │   │       ├── gridlayout_posix
│       │   │       │   └── module_ActsGridLayoutTest.ninja
│       │   │       ├── image_posix
│       │   │       │   └── module_ActsImageTest.ninja
│       │   │       ├── interpolation_posix
│       │   │       │   └── module_ActsInterpoliationTest.ninja
│       │   │       ├── layout_posix
│       │   │       │   └── module_ActsLayoutTest.ninja
│       │   │       ├── listlayout_posix
│       │   │       │   └── module_ActsListlayoutTest.ninja
│       │   │       ├── screen_posix
│       │   │       │   └── module_ActsScreenTest.ninja
│       │   │       ├── style_posix
│       │   │       │   └── module_ActsStyleTest.ninja
│       │   │       ├── theme_posix
│       │   │       │   └── module_ActsThemeTest.ninja
│       │   │       ├── ui_abstract_progress_posix
│       │   │       │   └── module_ActsUIAbstractProgressTest.ninja
│       │   │       ├── ui_analog_clock_posix
│       │   │       │   └── module_ActsUIAnalogClockTest.ninja
│       │   │       ├── uianimator_posix
│       │   │       │   └── module_ActsUIAnimatorTest.ninja
│       │   │       ├── ui_arc_lable_posix
│       │   │       │   └── module_ActsUIArcLabelTest.ninja
│       │   │       ├── ui_axis_posix
│       │   │       │   └── module_ActsUIAxisTest.ninja
│       │   │       ├── ui_box_porgress_posix
│       │   │       │   └── module_ActsUIBoxProgressTest.ninja
│       │   │       ├── ui_button_posix
│       │   │       │   └── module_ActsUIButtonTest.ninja
│       │   │       ├── ui_canvas_posix
│       │   │       │   └── module_ActsUICanvasTest.ninja
│       │   │       ├── ui_chart_posix
│       │   │       │   └── module_ActsUIChartTest.ninja
│       │   │       ├── ui_checbox_posix
│       │   │       │   └── module_ActsUICheckboxTest.ninja
│       │   │       ├── ui_circle_progress_posix
│       │   │       │   └── module_ActsUICircleProgressTest.ninja
│       │   │       ├── ui_digital_clock_posix
│       │   │       │   └── module_ActsUIDigitalClockTest.ninja
│       │   │       ├── ui_image_animator_posix
│       │   │       │   └── module_ActsUIImageAnimatorTest.ninja
│       │   │       ├── ui_image_posix
│       │   │       │   └── module_ActsUIImageTest.ninja
│       │   │       ├── ui_label_button_posix
│       │   │       │   └── module_ActsUILabelButtonTest.ninja
│       │   │       ├── ui_label_posix
│       │   │       │   └── module_ActsUILabelTest.ninja
│       │   │       ├── ui_list_posix
│       │   │       │   └── module_ActsUIListTest.ninja
│       │   │       ├── ui_picker_posix
│       │   │       │   └── module_ActsUIPickerTest.ninja
│       │   │       ├── ui_radio_button_posix
│       │   │       │   └── module_ActsUIRadioButtonTest.ninja
│       │   │       ├── ui_repeat_button_posix
│       │   │       │   └── module_ActsUIRepeatButtonTest.ninja
│       │   │       ├── ui_screenshot_posix
│       │   │       │   └── module_ActsUIScreenshotTest.ninja
│       │   │       ├── ui_scroll_view_posix
│       │   │       │   └── module_ActsUIScrollViewTest.ninja
│       │   │       ├── ui_slider_posix
│       │   │       │   └── module_ActsUISliderTest.ninja
│       │   │       ├── ui_surface_view_posix
│       │   │       │   └── module_ActsUISurfaceViewTest.ninja
│       │   │       ├── ui_swipe_view_posix
│       │   │       │   └── module_ActsUISwipeViewTest.ninja
│       │   │       ├── ui_text_posix
│       │   │       │   └── module_ActsUITextTest.ninja
│       │   │       ├── ui_texture_mapper_posix
│       │   │       │   └── module_ActsUITextureMapperTest.ninja
│       │   │       ├── ui_time_picker_posix
│       │   │       │   └── module_ActsUITimePickerTest.ninja
│       │   │       ├── ui_toggle_button_posix
│       │   │       │   └── module_ActsUIToggleButtonTest.ninja
│       │   │       ├── ui_view_group_posix
│       │   │       │   └── module_ActsUIViewGroupTest.ninja
│       │   │       └── ui_view_posix
│       │   │           └── module_ActsUIViewTest.ninja
│       │   ├── hiviewdfx_lite
│       │   │   └── hilog_posix
│       │   │       └── module_ActsHilogTest.ninja
│       │   ├── kernel_lite
│       │   │   ├── dyload_posix
│       │   │   │   └── module_ActsDyloadTest.ninja
│       │   │   ├── fs_posix
│       │   │   │   ├── jffs
│       │   │   │   │   └── module_ActsJFFS2Test.ninja
│       │   │   │   ├── nfs
│       │   │   │   │   └── module_ActsNFSTest.ninja
│       │   │   │   ├── vfat
│       │   │   │   │   └── module_ActsVFATTest.ninja
│       │   │   │   └── vfat_storage
│       │   │   │       └── module_ActsVFATstorageTest.ninja
│       │   │   ├── futex_posix
│       │   │   │   └── module_ActsFutexApiTest.ninja
│       │   │   ├── io_posix
│       │   │   │   └── module_ActsIoApiTest.ninja
│       │   │   ├── ipc_posix
│       │   │   │   ├── message_queue
│       │   │   │   │   └── module_ActsIpcMqTest.ninja
│       │   │   │   ├── pipe_fifo
│       │   │   │   │   └── module_ActsIpcPipeTest.ninja
│       │   │   │   ├── semaphore
│       │   │   │   │   └── module_ActsIpcSemTest.ninja
│       │   │   │   ├── shared_memory
│       │   │   │   │   └── module_ActsIpcShmTest.ninja
│       │   │   │   └── signal
│       │   │   │       └── module_ActsIpcSignalTest.ninja
│       │   │   ├── math_posix
│       │   │   │   ├── complexTest.ninja
│       │   │   │   └── module_ActsMathApiTest.ninja
│       │   │   ├── mem_posix
│       │   │   │   └── module_ActsMemApiTest.ninja
│       │   │   ├── net_posix
│       │   │   │   └── module_ActsNetTest.ninja
│       │   │   ├── process_posix
│       │   │   │   └── module_ActsProcessApiTest.ninja
│       │   │   ├── sched_posix
│       │   │   │   └── module_ActsSchedApiTest.ninja
│       │   │   ├── sys_posix
│       │   │   │   └── module_ActsSysApiTest.ninja
│       │   │   ├── time_posix
│       │   │   │   └── module_ActsTimeApiTest.ninja
│       │   │   ├── util_posix
│       │   │   │   └── module_ActsUtilApiTest.ninja
│       │   │   └── utils
│       │   │       ├── libfs.ninja
│       │   │       ├── libmt_utils.ninja
│       │   │       └── libutils.ninja
│       │   ├── multimedia_lite
│       │   │   └── media_lite_posix
│       │   │       └── recorder_native
│       │   │           └── module_ActsMediaRecorderTest.ninja
│       │   ├── security_lite
│       │   │   ├── datahuks_posix
│       │   │   │   └── module_ActsSecurityDataTest.ninja
│       │   │   └── permission_posix
│       │   │       ├── capability
│       │   │       │   ├── capability_shared.ninja
│       │   │       │   ├── jffs
│       │   │       │   │   └── module_ActsJFFS2CapabilityTest.ninja
│       │   │       │   └── vfat
│       │   │       │       └── module_ActsVFATCapabilityTest.ninja
│       │   │       ├── dac
│       │   │       │   ├── jffs
│       │   │       │   │   └── module_ActsJFFS2DACTest.ninja
│       │   │       │   └── vfat
│       │   │       │       └── module_ActsVFATDACTest.ninja
│       │   │       └── pms
│       │   │           └── module_ActsPMSTest.ninja
│       │   ├── startup_lite
│       │   │   ├── bootstrap_posix
│       │   │   │   └── module_ActsBootstrapTest.ninja
│       │   │   └── syspara_posix
│       │   │       └── module_ActsParameterTest.ninja
│       │   └── utils_lite
│       │       └── kv_store_posix
│       │           └── module_ActsKvStoreTest.ninja
│       └── tools
│           └── lite
│               ├── hcpptest
│               │   ├── gmock_main.ninja
│               │   ├── gmock.ninja
│               │   ├── hcpptest_main.ninja
│               │   └── hcpptest.ninja
│               └── others
│                   └── query
│                       └── query.ninja
├── third_party
│   ├── bounds_checking_function
│   │   ├── libsec_shared.ninja
│   │   └── libsec_static.ninja
│   ├── freetype
│   │   └── freetype.ninja
│   ├── giflib
│   │   └── libgif.ninja
│   ├── iniparser
│   │   └── iniparser.ninja
│   ├── libjpeg
│   │   └── libjpeg.ninja
│   ├── libpng
│   │   └── libpng.ninja
│   ├── mbedtls
│   │   ├── mbedtls_gt.ninja
│   │   ├── mbedtls_shared.ninja
│   │   └── mbedtls_static.ninja
│   └── qrcodegen
│       └── qrcodegen.ninja
├── utils
│   └── native
│       └── lite
│           ├── kv_store
│           │   └── src
│           │       └── utils_kv_store.ninja
│           └── os_dump
│               └── os_dump.ninja
└── vendor
    └── hisilicon
        └── hispark_aries
            └── hals
                ├── security
                │   └── permission_lite
                │       └── hal_pms.ninja
                └── utils
                    ├── sys_param
                    │   └── hal_sysparam.ninja
                    └── token
                        └── haltoken_shared.ninja

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579

百文说内核 | 抓住主脉络

  • 百文相当于摸出内核的肌肉和器官系统,让人开始丰满有立体感,因是直接从注释源码起步,在加注释过程中,每每有心得处就整理,慢慢形成了以下文章。内容立足源码,常以生活场景打比方尽可能多的将内核知识点置入某种场景,具有画面感,容易理解记忆。说别人能听得懂的话很重要! 百篇博客绝不是百度教条式的在说一堆诘屈聱牙的概念,那没什么意思。更希望让内核变得栩栩如生,倍感亲切。
  • 与代码需不断debug一样,文章内容会存在不少错漏之处,请多包涵,但会反复修正,持续更新,v**.xx 代表文章序号和修改的次数,精雕细琢,言简意赅,力求打造精品内容。
  • 百文在 < 鸿蒙研究站 | 开源中国 | 博客园 | 51cto | csdn | 知乎 | 掘金 > 站点发布,百篇博客系列目录如下。

按功能模块:

基础知识 进程管理 任务管理 内存管理
双向链表
内核概念
源码结构
地址空间
计时单位
优雅的宏
钩子框架
位图管理
POSIX
main函数
调度故事
进程控制块
进程空间
线性区
红黑树
进程管理
Fork进程
进程回收
Shell编辑
Shell解析
任务控制块
并发并行
就绪队列
调度机制
任务管理
用栈方式
软件定时器
控制台
远程登录
协议栈
内存规则
物理内存
内存概念
虚实映射
页表管理
静态分配
TLFS算法
内存池管理
原子操作
圆整对齐
通讯机制 文件系统 硬件架构 内核汇编
通讯总览
自旋锁
互斥锁
快锁使用
快锁实现
读写锁
信号量
事件机制
信号生产
信号消费
消息队列
消息封装
消息映射
共享内存
文件概念
文件故事
索引节点
VFS
文件句柄
根文件系统
挂载机制
管道文件
文件映射
写时拷贝
芯片模式
ARM架构
指令集
协处理器
工作模式
寄存器
多核管理
中断概念
中断管理
编码方式
汇编基础
汇编传参
链接脚本
内核启动
进程切换
任务切换
中断切换
异常接管
缺页中断
编译运行 调测工具
编译过程
编译构建
GN语法
忍者无敌
ELF格式
ELF解析
静态链接
重定位
动态链接
进程映像
应用启动
系统调用
VDSO
模块监控
日志跟踪
系统安全
测试用例

百万注源码 | 处处扣细节

  • 百万汉字注解内核目的是要看清楚其毛细血管,细胞结构,等于在拿放大镜看内核。内核并不神秘,带着问题去源码中找答案是很容易上瘾的,你会发现很多文章对一些问题的解读是错误的,或者说不深刻难以自圆其说,你会慢慢形成自己新的解读,而新的解读又会碰到新的问题,如此层层递进,滚滚向前,拿着放大镜根本不愿意放手。

  • < gitee | github | coding | gitcode > 四大码仓推送 | 同步官方源码。

关注不迷路 | 代码即人生

  • 互联网从业十五年,计算机硕士,技术副总裁
  • 关注我,持续更新四十年,即聊技术也聊人生
  • 交有趣靠谱的人;做难而正确的事
  • 不做作,不炒作,只唯真
  • 不唯上,不唯书,只唯实

>> 捐助名单

据说喜欢 点赞 + 分享 的,后来都成了大神。😃
